SMA-to-SMA
Ready to Go
Plug one end of the SMA-to-SMA antenna cable into the UC10x, and the other end into any SMA transponder antenna (e.g. UC333) and it is ready to go.
Field Tested
This cable—combined with the SMA Monopole Antenna—have proven range even on the smallest UAV with composite contruction.
| Length | 12 in. (0.32 meters) |
| Frequency | DC to 3 GHz |
| Impedance | 50 Ohms |
| Insertion Loss @ 1 GHz | 0.3 dB typ, 0.5 dB max |
| Cable Type | RG316 Coax |
| Termination #1 | SMA Male (Cable) |
| Polarity | Normal |
| Cycles | 25 |
| Termination #2 | SMA Female (Bulkhead) |
| Polarity | Normal |
| Cycles | 25 |
- UC323 Antenna Cable, SMA-to-SMA
- Test Data (with cable loss)
- Certificate of Conformance (CoC)
Login required. Please Contact Us to access downloads, FAQs, articles, help desk support, and more through our Support Portal.
Documentation
UC323 Drawing, Antenna Cable, SMA-to-SMA.pdf
Volume Customer/OEM Information
UC323 Product Change Notices.pdf ← NO PCNs YET, STILL VERSION -00. Sign up here for automatic email notifications.
Urban Canyon Quality Manual.pdf ← COMING SOON
